Solution for Satellite Waveguide Slip Ring

JINPAT
Add to MyDirectIndustry favorites

JINPAT has manufactured varied slip rings that have been applied in multifarious fields.

As to waveguide for satellite, JINPAT has developed rotary joint that integrates electrical part and waveguide rotary joint. Its waveguide frequency can reach 110 GHz and 18GHz for the coaxial part. The rotary joint is capable of integrating signals channels of multiple types. With a reliable performance and ultra-long service life, it has been mainly applied in radar antenna, communication on the move, on-the-move antenna.

Such a slip ring can work in a low temperature down to -55℃。 Moreover, the waveguide slip ring enjoys a low voltage stationary wave ratio (VSWR).

Satellite Waveguide Rotary Joint
Satellite Waveguide Rotary Joint

Through Bore Slip Ring
