Cubic Gas Sensing Solution for Spirometry Test

Innovative Gas Sensing Solutions for Advanced Spirometry Testing

The cardiopulmonary system stands as a cornerstone of human physiology, tasked with the vital function of efficiently distributing blood and oxygen to every organ in the body. Given its profound impact on overall health, the evaluation of pulmonary function through diagnostic testing is critical.

Among a series of diagnostic tools, spirometry emerges as the most commonly utilized method among others, providing a comprehensive assessment of lung function by measuring critical parameters such as flow rate and volume.

The key to spirometry tests lies in obtaining accurate gas measurement data, aiding healthcare professionals in determining the outcomes for the individual being tested.

With 20-year dedication to the development of gas sensing technologies, Cubic, an international manufacturer of advanced gas sensors and gas analyzers, has accumulated mature sensing technology platform of non-dispersive infrared (NDIR) to deliver diverse gas sensing solutions supporting spirometry test.

Ultrasonic Sensing Technology:

Ultrasonic gas flow sensors adopt ultrasonic detecting technology and the principle of TOF (time of flight) to measure both the gas flow rate and gas composition in binary gases, which involves monitoring and analyzing the changes in acoustic waves as they travel through a gas mixture. Ultrasonic gas sensors typically utilize two ultrasonic transducers, each functioning as both emitter and receiver, exchanging ultrasonic pulses. By assessing the variance between pulses traveling upstream and downstream within a pipeline, ultrasonic gas sensors can accurately determine gas flow rates. Additionally, as the speed of sound varies among different gases, analyzing the speed of ultrasonic pulses through the gas facilitates precise gas composition analysis.

Cubic high-tech spirometers Gasboard 7020 and Gasboard 7021 are developed based on the ultrasonic detecting technology to provide respiratory function measurement solutions.

Cubic Ultrasonic Spirometer Gasboard 7020 for Hospital Use：

Cubic Gasboard 7020 is a handheld spirometer developed specifically for hospital settings, equipped with a set of advanced functionalities. Utilizing Cubic's advanced ultrasonic gas flow sensor, it excels in delivering precise measurements of critical respiratory parameters. From static vital capacity to forced vital capacity and maximum voluntary ventilation rate, Gasboard 7020 delivers reliable measurement results for respiratory conditions. Its sophisticated software enables real-time curve display, ensuring healthcare professionals have immediate access to vital measurements. With automatic BTPS correction, Gasboard 7020 ensures accurate measurement results, allowing for confident diagnosis and treatment planning. Moreover, Gasboard 7020 streamlines patient information management, offering seamless integration with clinical workflows. In summary, Gasboard 7020 serves as a valuable tool for healthcare professionals, enhancing efficiency and efficacy in respiratory care management.

Cubic Ultrasonic Spirometer Gasboard 7021 for Home Use：

Cubic Gasboard 7021 is a portable spirometer designed for convenient home use. Employing ultrasonic technology, it ensures precise measurements of pulmonary ventilation function, ensuring comprehensive respiratory health monitoring from the comfort of home. Designed with the user in mind, its lightweight construction and intuitive real-time graphic data display empower patients to conduct tests with ease and interpret results effortlessly. Beyond the testing experience, Gasboard 7021 is equipped with intelligent information management software, seamlessly organizing historical test results for quick reference and in-depth analysis. The comprehensive feature set of Gasboard 7021 not only enhances user convenience but also facilitates informed decision-making and proactive management of respiratory health.
