D-FL 100 Volume flow measuring system

Suitability-tested and certified impact pressure system to measure velocity and volume flow of dry flue gas or process gas in pipes or ducts.

- In situ measurement, continuous measurement

- Allows calibration to measure the volume flow

- Cross duct, half duct and single point versions

- Also suitable for thick-walled stone / insulated ducts

- Probe is in contact with sample gas, backpurge as an option

- Automatic zero check as an option

- Universal operation unit D-ISC 100 as an option

- Temperature and pressure sensor as option

- Normalization of the flow measurements as an option

- Very low maintenance

Suitable for velocity and volume flow measurement

- at incinerators with dry fluegas in general

- at installations in accordance with IED 2010/75/EU/ 17th BImschV

- at garbage, hazardous waste and sewage sludge incinerators,

- at facilities for cement production

- at installations in accordance with 2001/80/EC LCPD / 13th BImschV / Clean Air Act

- at power stations with gas, oil, coal or co-firing

- at facilities pursuant to 27th BImschV

- for processes, Ex zones, high temperature or high pressure applications
