Liquid Cooling Manifold Evolves Into Core Infrastructure for High Density AI Data Centers

From Air Conditioner Auxiliary to Vascular Hub: Why 100kW Cabinets Made Manifolds Indispensable

The liquid cooling manifold has evolved from an auxiliary component inside precision air conditioners into core infrastructure for high-density AI data centers, as single-cabinet heat loads surge from 20kW beyond 100kW, breaking air cooling's limits and demanding fully sealed, leak-proof pipelines. Zero leakage, precise fluid delivery and hot-swap maintainability are now key requirements. Oetiker, with over 80 years of connection expertise, delivers stepless single-ear hose clamps providing 360° uniform compression to eliminate leakage, plus high-flow, error-proof QCDC quick connectors that reduce fluid loss and downtime. EXTRCOOL provides one-stop liquid cooling solutions.

More information

Details

Area 51, NV, USA

EXTRCOOL INDUSTRY LIMITED
