Testing the Heart of Liquid Cooling, Zhuomao Instruments' Complete CDU Qualification Line

Performance, Aging, Cleaning and Seal Verification: The Five-Stage Qualification Line Every CDU Must Pass

At the center of liquid cooling sits the CDU—integrating pump, heat exchanger, sensors and control in a closed loop—and Zhuomao Instruments offers a complete qualification line: performance testing, aging testing, re-testing, cleaning and drying, and vacuum nitrogen filling with pressure holding. Performance testing covers 0-500 LPM at ±0.5% F.S., 0-1000 kPa at ±0.25% F.S., with aging tests reproducing full-lifecycle conditions. The cleaning system achieves metal particles no larger than 50 μm and non-metal particles no larger than 150 μm, and the vacuum nitrogen system evacuates to -100 kPa to pinpoint leaks before shipment. EXTRCOOL provides one-stop liquid cooling solutions.

More information

Details

Area 51, NV, USA

EXTRCOOL INDUSTRY LIMITED

Associated Trend items

The CDU, the Heart and Brain Liquid Cooling Cannot Do Without

Silent When Healthy, Fatal When Failing: The Five Selection Questions That Decide Whether the CDU Holds the Loop Together

The CDU plays the role the heart plays: it produces no cold, but without it the coolant never moves. Its heart role pumps and distributes via the manifold, while its brain role senses and controls. Selection answers five questions: total flow above all cold plate minimums, head above maximum loop resistance, exchanger capacity above peak load with fouling margin, redunda...

More information

The Manifold That Decides Where the Coolant Goes

From CDU to Cold Plate and Back: How the Manifold's Flow Distribution, Not Total Flow, Decides Precision Cooling

Rising AI GPU power is moving liquid cooling from whether it can cool to cooling precisely, and the manifold decides whether coolant reaches every position as it should. It distributes coolant through main channels to parallel branches and collects the heated return, following CDU to supply manifold to cold plate to return manifold to CDU. Poor design lets near-end branc...

More information

How a Liquid Cooling Manifold Gets Made, from Material to Final Acceptance

316L to Helium Testing: The Four Links—Material, Machining, Cleanliness and Verification—That Decide Manifold Quality

Manifold manufacturing starts with material, and 316L is the safer default, with coolant compatibility outweighing thermal conductivity. CNC machining forms main channels, branches and interface holes, where holding channel positions matters more than drilling; one-piece machining avoids weld deformation, while tube and plate assemblies add laser, TIG or brazing. Deburri...

More information
