IEG-INOX-MP

VERSATILITY IS OUR STRENGTH

One of the main strengths of F.lli Giacomello SRL is the ability to create tailor-made products for its customers. The search for the greatest possible versatility, has always been a company constant. This has led to the birth of IEG-INOX-MP, multi-point level indicators, which thanks to their versatility are able to satisfy the most diverse needs.

The IEG-MPs are built to guarantee, with maximum safety, different control points in tanks containing corrosive and non-corrosive substances. In fact, being made entirely of AISI 316 stainless steel, they can also be applied in the food, chemical and pharmaceutical industries.

Furthermore, the high corporate standards of F.lli Giacomello, have allowed the approval of this product to the Lloyd’s standards, destining them also to the naval field, thanks to the Type Approval Certificate of Lloyd’s register.

But how do these level indicators work?

When the indicator float in its travel meets the Reed switch incorporated in the tube at the predetermined distance, the contact, solicited by the magnet housed in the float, opens or closes, thus having the possibility of remotely sending a light recall signal , acoustic or to interrupt any electrical equipment connected to it.

The indicator must be assembled in a vertical position, with the warning that the float is away from ferrous surfaces (walls, tanks, etc.) minimum 35mm.

The product also has other important features:

- Owns 3 to 9 check points

- Threaded and flanged process connections

- Possibility of thermostat or PT100.

- Maximum operating pressure: 10 Bar.

Number of contacts, lengths or types of heads are always performed on customer request.

Precision and functionality, single or multiple control points, different materials make the IEG-INOX-MP the ideal product to satisfy the most varied application needs.
