JAD Shell-and-Coil Heat Exchanger – High-Efficiency Solution for Demanding Applications

Advanced heat transfer technology designed for real-world industrial performance

In modern industrial and HVAC systems, efficiency, reliability and compactness are no longer optional. The HEXONIC JAD shell-and-coil heat exchanger is engineered to deliver superior thermal performance where conventional shell-and-tube exchangers reach their limits.

Designed for demanding applications, JAD combines innovative coil geometry, premium stainless steel construction and a space-saving vertical design to provide a long-term, energy-efficient solution for heat transfer processes.

Why choose the JAD shell-and-coil heat exchanger?
Compact design with exceptional thermal efficiency

The unique shell-and-coil configuration allows significantly higher heat transfer rates compared to traditional designs. Thanks to its vertical orientation, the JAD exchanger requires minimal floor space, making it ideal for modern plant rooms and compact installations.

Higher performance. Smaller footprint. Easier integration.

Corrugated tubes for maximum heat transfer

At the core of the JAD design are corrugated stainless steel tubes, which increase flow turbulence and enhance the overall heat transfer coefficient. This results in:

higher thermal efficiency

improved performance at lower flow rates

reduced energy consumption

Reduced fouling and lower maintenance costs

The optimized internal flow path and X-type connections minimize dead zones and fouling risks. This ensures:

stable long-term performance

extended service intervals

lower total cost of ownership (TCO)

Versatile applications across industries

The JAD shell-and-coil heat exchanger is suitable for a wide range of applications, including:

heat pumps

domestic hot water systems

district heating substations

industrial process heating

steam and condensate systems

cooling and HVAC installations

food, pharmaceutical and chemical industries

Premium materials and certified quality

All JAD heat exchangers are manufactured from high-grade austenitic stainless steel (e.g. AISI 316L), ensuring excellent corrosion resistance and durability even in aggressive environments.

The design complies with PED and ASME standards, simplifying approval processes and enabling global project implementation.

Energy efficiency that delivers measurable savings

Compared to conventional shell-and-tube exchangers, shell-and-coil technology offers:

higher efficiency per unit volume

reduced pumping energy

lower installation and operational costs

This makes JAD not only a technical solution, but a strategic investment with fast return.

JAD by HEXONIC – Engineered for professionals

The JAD series is developed for engineers, designers and system integrators who demand:

predictable performance

compact and flexible installation

long service life

reliable manufacturer support

Looking for the optimal solution for your project?

Use our HEXONIC CAIRO selection software or contact our technical experts to find the right JAD configuration for your specific application.
