Anti-Condensation Silicone Hose for Temperature-Controlled Applications

Ideal for food, pharma, and biotech industries requiring dry surfaces, thermal stability, and contamination-free operations.

What is ImaCondense™?
• ImaCondense™ is a unique and innovative anti-condensation insulating material developed by Ami Polymer.
• It is specifically designed for applications where moisture control, hygiene, and temperature stability are critical.
• Unlike conventional insulation sleeves, ImaCondense™ forms a chemical bond with the silicone hose, ensuring:
- Perfect adhesion between layers
- Zero risk of peeling or delamination
- Long-lasting and maintenance-free performance
This makes it a one-piece, integrated anti-condensation hose system, unmatched in the market.

Key Features
Excellent Anti-Condensation Performance
• Prevents condensation formation on cold surfaces
• Completely eliminates external moisture build-up
• Keeps the hose surface dry, clean, and safe

Superior Thermal Insulation
• Low thermal conductivity for high insulation efficiency
• Minimizes heat loss and energy wastage
• Maintains the temperature of the fluid flowing inside the hose

Wide Operating Temperature Range
• Operates efficiently from –20°C to +230°C
• Suitable for frozen, chilled, ambient, and hot applications

Strong & Flexible Construction
• Highly resistant to wear and tear
• Designed for long service life
• Easy to install with excellent flexibility for complex routing

Industries & Applications
• Food & Beverage Processing
• Pharmaceutical Manufacturing
• Biotech & Laboratory Systems
• Cosmetic Industry
• Dairy Processing Plants
• Water Treatment Facilities
• HVAC & Cooling Systems
• Frozen & Chilled Liquid Transfer Lines

Certifications & Regulatory Compliance
• FDA 21 CFR 177.2600 – Food Grade Compliance
• USP Class VI – ISO 10993-1 Biocompatibility
• RoHS Compliant – Free from Phthalates, Bisphenol, and Volatile Plasticizers
• TSE / BSE Certified
• Toxikon-based Extractables & Leachables (E&L) studies available
• Complete validation documentation available upon request

Size Chart – ImaCondense™ Anti-Condensation Silicone Hose

Part No. Hose Size Inner Bending Min Wall Max Working Min Burst
(ID × OD) Diameter Radius Thickness Pressure Pressure
AC9.0 9.0 × 29.0 mm 9.0 mm 42 mm 10.0 mm 14 Bar 100 Bar
AC12.0 12.0 × 33.0 mm 12.0 mm 41 mm 10.5 mm 13.5 Bar 100 Bar
AC16.0 16.0 × 37.0 mm 16.0 mm 38 mm 10.5 mm 12.5 Bar 120 Bar
AC19.0 19.0 × 40.0 mm 19.0 mm 34 mm 10.5 mm 11.5 Bar 130 Bar
AC25.0 25.0 × 48.0 mm 25.0 mm 32 mm 11.5 mm 10.5 Bar 220 Bar
AC32.0 32.0 × 55.0 mm 32.0 mm 30 mm 11.5 mm 10.0 Bar 250 Bar
AC38.0 38.0 × 63.0 mm 38.0 mm 30 mm 12.5 mm 10.0 Bar 280 Bar

Conclusion
• ImaCondense™ Anti-Condensation Flexible Silicone Hose is a best-in-class solution for industries handling cold or temperature-sensitive fluids.
• It eliminates condensation, reduces heat loss, and maintains high hygiene standards.
• It significantly improves system performance, safety, and reliability.
• For applications where moisture control, thermal insulation, and regulatory compliance are non-negotiable, ImaCondense™ is the ultimate choice.
