Posted on 11/4/2014
12.5 x 103.5 x 72 mm. Those are the dimensions of the super-compact, fully integrated servo amplifier from SIGMATEK’s S-DIAS series. The DC 061, with a power rating of nearly 300 W, is designed to control a synchronous servo motor up to 6 Amperes of continuous current at 48 V DC. Over short period of time, the DC 061 can even output a peak current of up to 15 Amperes. With this power, highly dynamic positioning tasks can be run quickly and precisely in combination with the fast regulation technology.
The integrated standard resolver input (12 bits) enables economic feedback analysis (position feedback). A 24 V DC output is also provided for regenerative braking control. The integrated energy recovery in the intermediate circuit during braking maximizes energy efficiency; especially in multi-axis systems.
The DC 061 is equipped with a 2-channel Enable input, which...
