Absolute measurement, precise positioning

HIWIN expands its portfolio with the APM Absolute Position Measurement System

With the new APM Absolute Position Measurement System, HIWIN GmbH is expanding its portfolio of precision linear axes to include a further key component for end-to-end positioning solutions from a single source. When used in conjunction with HIWIN linear axes, the measurement system is available as a fully integrated solution. This simplifies design and commissioning, reduces the number of interfaces and enables precise and reliable position detection.

In addition to its tried-and-tested incremental position measurement systems, HIWIN now also offers an absolute measurement system. The magnetically encoded, non-contact measurement solution detects the current position immediately after the system is switched on. There is no need for reference runs, meaning machines and systems are ready for operation again much more quickly. Integrated space-savingly inside the axis, the electrical connection is made via a BiSS-C interface, enabling easy integration into modern automation environments.
Developed specifically for automated positioning tasks, the APM ensures reliable position detection even under demanding environmental conditions involving oil, dirt, vibrations or shocks.
A particular advantage also lies in HIWIN’s integrated system approach. Users receive a fully coordinated complete solution comprising a linear axis, distance measuring system, motor and drive technology, all from a single source. For users, this means fewer interfaces, reduced integration effort and faster implementation of automation projects.

Whether incremental or Absolute Position Measurement System: HIWIN offers the right solution for a wide range of requirements and continues to expand its portfolio for motion and drive technology.
Suitable linear axes, including the required position measurement system, can be easily selected and configured using the HIWIN product configurator:
https://www.hiwin.de/en/cad-konfigurator/Produkte/cdlc/3952
