JINPAT Pneumatic-Hydraulic Integrated Slip Ring Assists in Upgrading Automation Equipment

JINPAT Pneumatic-Hydraulic Integrated Slip Ring Assists in Upgrading Automation Equipment

Overcoming Rotation Challenges: The "Hub" for Multi-Media Transport
In modern automated production lines, robotic arms or turntables often require "simultaneous power supply" or even "simultaneous gas/liquid flow." The JINPAT integrated gas-liquid slip ring, through its innovative internal structure, solves the winding problem, ensuring rock-solid current, signal, and liquid transport even during continuous equipment rotation.

Hardcore Performance: Born for Harsh Environments
This integrated slip ring, customized for automated equipment, not only boasts robust internal components but also excellent environmental adaptability:

Comprehensive Protection: IP65-rated high-strength protection effectively isolates dust and water mist in industrial environments.

Extreme Tolerance: Operating temperature ranges from -20°C to +60°C, unaffected by extreme temperatures, ensuring year-round production line operation.

Compact Design: With a diameter of only 86mm and a length of 249.2mm, it achieves miniaturization and weight reduction with extremely high power density in the space-constrained environment of precision equipment.

Powerful Integration: Multi-dimensional channels, one-click configuration
The JINPAT R&D team has achieved extremely high integration within a limited volume to meet diverse process requirements:

4-channel liquid transfer: Designed specifically for cooling, hydraulics, or lubrication, with excellent fluid channel sealing.

High Current Support: Equipped with 6 16A power channels, easily driving high-power motors and actuators.

Precision Signals: Reserved 3 signal channels to ensure zero distortion and low loss of various sensor data and control signals during transmission.

Application Scenarios: Empowering Smart Manufacturing

Automated Filling Line: Liquid flows through, electrically controlled, achieving efficient rotary filling.

Industrial Robotic Arm: Provides pneumatic/hydraulic power and multi-channel electrical control for the end effector.

Precision Rotary Table: Ensuring real-time feedback of complex data while maintaining high-speed rotation.

JINPAT is committed to solving the rotary transmission challenges faced by customers worldwide. If you are looking for a slip ring with high protection, long lifespan, and fluid integration capabilities, this 86mm diameter series is the ideal choice.

Contact us now for professional custom rotary solutions!
