IEC 60068-2-13:2021 Low Pressure Test: Sanwood Technology Altitude Test Chamber

Sanwood Technology Altitude Test Chamber strictly follow IEC international standards, accurately simulate high-altitude and low-pressure environments, and provide reliable testing solutions for aerospace and other fields.

In the aerospace industry, product reliability and safety are directly linked to mission success and personnel safety. Extreme low-pressure environments are one of the most challenging challenges that aircraft and electronic equipment must overcome. SANWOOD Technology independently developed Altitude Test Chamber, strictly adhering to the IEC 60068-2-13:2021 testing standard, provides the industry with highly realistic low-pressure testing conditions to ensure stable performance and full functionality of various components in high-altitude environments. This highly realistic simulation allows engineers to efficiently evaluate the performance and reliability of materials and components in low-pressure conditions, providing data support for product optimization.

IEC 60068-2-13:2021, an environmental testing standard published by the International Electrotechnical Commission (IEC), is known as "Environmental testing - Part 2-13: Tests - Test M: Low air pressure." This standard specifies test methods applicable to samples that may be exposed to low air pressure during transportation, storage, or use. Its purpose is to determine the ability of components, equipment, or other items to be used, transported, or stored in low-pressure environments.

SANWOOD Technology Altitude Test Chamber parameters
SANWOOD Technology Altitude Test Chamber can be customized according to customer specifications. The following are the basic technical parameters of the test chamber:
Temperature range: -25°C to +50°C, constant temperature, heating load 34kW
Temperature fluctuation: ≤±0.5°C (at atmospheric pressure, unloaded)
Temperature deviation: ≤±2.0°C (at atmospheric pressure, unloaded)
Temperature uniformity: ≤2.0°C (at atmospheric pressure, unloaded)
Pressure range: atmospheric pressure to 80.0kPa
Pressure deviation: ≤±2kPa
Using conditions: Ambient temperature: 5°C to 35°C
Ambient humidity: ≤85%RH
Cooling water temperature: ≤32°C
Cooling water pressure: 0.25 to 0.4MPa
Cooling water flow rate: 20 tons/hour
SANWOOD Technology Altitude Test Chamber strictly adheres to international standards such as IEC 60068-2-13:2021 to ensure the accuracy of test results.

Features of SANWOOD Technology Altitude Test Chambers
1. Excellent constant temperature performance and pressure control within the test chamber.
2. Large-Capacity Design: Compared to traditional test chambers, large high-altitude test chambers offer a larger interior space, accommodating larger equipment and samples.
3. High-Altitude Environment Simulation: Simulates high altitude conditions, low pressure, and low temperatures to test product performance in such environments.
4. Temperature Compensation During Vacuuming: Due to the thin air and poor convective heat transfer, the chamber temperature may be uneven. The system requires heating to compensate for the temperature drop caused by vacuuming to accurately achieve the desired temperature point.
5. Different temperature and humidity profiles and test times can be set; the chamber volume, temperature, and appearance can be customized.
6. The chamber is equipped with a dedicated pressure control system that precisely controls and maintains the desired low pressure by adjusting the vacuum pump valve opening or pump power.

SANWOOD Technology is always by your side as you explore the unknown and challenge your limits. SANWOOD Technology Altitude Test Chamber strictly adhere to the international standard IEC 60068-2-13:2021. With precise air pressure control, excellent constant temperature performance, and customizable designs, they provide support for reliability testing in aerospace, electric vehicles, military, and other fields. SANWOOD Technology also offers testing equipment such as Temperature Humidity Test Chamber, Rapid Temperature Change Test Chamber, and AGREE Test Chamber that meet international standards, supporting personalized customization. For professional testing solutions, please contact SANWOOD Technology and we will provide tailored professional services.
