Linear Actuator Motor 22MM Screw Drive

Modified & Custom Solutions‎, Manufacturers & Suppliers‎

Voltage: customizable

Spindle Length: 150mm

Max Feed Velocity: 35mm/s

Max Force for Press Fit: 550N

Radial Play: max 0.05mm, 5mm from flange

Temperature Range: -15……+80℃

Noise: lower than 50dB (under stable circumstances)

Planetary Gearheads Specs:

Number of Stages 1 2 3 4

Reduction Ratio 4/6 14/19/20/24/29

53/62/72/76/84/89/

104/109/128

157/198/231/270/285/316/333/

370/389/410/455/479/561/590/690/850

Max Feed Velocity (mm/s) 25-35mm/s 4.6-9.5mm/s 1-2.5 0.2-0.8

Max Force Continuous (N) 60-67N 92-118N 144-193 207-351

Max Force Intermittent (N) 167-188N 259-330N 351 351

The direction of Rotation, drive to output = = = =

Max Efficiency 35% 29% 25% 20%

Average Backlash No Load 1° 1.2° 1.6° 1.6°

Gearhead Length (mm) 38mm 44.8mm 51.6mm 58.4

Max Transmittable Power (Continuous) (W) 78-110W 14-30W 3.3-7.9W 0.49-2.7

Max Transmittable Power (Intermittent) (W) 120-180W 23-48W 5.2-13W 0.79-4.3

Screw Drive Specs:

Spindle Length (mm) 150mm 150mm 150mm 150mm

Radial Play (mm) max 0.05mm, 5mm from flange max 0.05mm, 5mm from flange max 0.05mm, 5mm from flange max 0.05mm, 5mm from flange

Axial Play of the Nut Max 0.0008mm Max 0.0008mm Max 0.0008mm Max 0.0008mm

Max Radial Load 80N, 15mm from flange 130N,15mm from flange 180N,15mm from flange 180N,15mm from flange

Max Force for Press Fit (N） 550N 550N 550N 390N

Max Continuous Input Speed 1875rpm 1875rpm 1875rpm 1875rpm

Max Intermittent Input Speed 7500rpm 7500rpm 7500rpm 7500rpm

Temperature Range -15……+80℃ -15……+80℃ -15……+80℃ -15……+80℃

Feature:

This screw drive consists of a motor, gearbox, lead screw. The Control system transmits instructions to the mechanical system, transforming the rotary motion of the motor into the linear motion of the lead screw. Thus, it achieves pushing, pulling, or lifting the load.

All the specifications of the screw drive can be customized according to your needs.

Multi-application. The 22MM screw drive can be used in various intelligent linear drive terminals, such as industrial/agricultural automation, patient lifter, automatic wheelchair, sit&stand lifting desk, traffic facilities, etc.
