Gear Motor for Touchless Trash Can

A Sensor Trash Can Using a Motion Sensor to Control the Trash Can

The touchless trash can is a sensor trash can using a motion sensor to control the trash can on and off, which frees people’s hands. Compared with the traditional trash can, it adds a set of electronic components and mechanical drive components to realizes smart control. The dive system for touchless trash can consists of a set of planetary gearbox and motor, which can reduce speed and improve torque. The planetary gearbox can be matched with different kinds of motor, such as DC brushed motor, DC brushless motor, stepper motor, and coreless motor. The technical parameters such as gear ratio, transmission noise, transmission precision, the structure of the gearbox are usually customized.

More information

Details

Shenzhen, Guangdong Province, China

ZHAOWEI

Associated Trend items

Gear Motor for Glass Arch Door Lock

DC Motor With Gear Reduction

Rated Voltage: 6V No-load Speed: 45±20% No-load Current: 300mA MAX Rated Loading Torque: 1000g.cm Rated Loading Current: 600mA MAX Locked-rotor Torque: 3g.cm REF Anti-drive Torque: 10KG.cm MAX Noise: ≤65dB under stable circumstances (test in 10cm away on the lateral side without windshield) Feature: The glass arch door is simple and beautiful. This gear motor c...

More information

Stroller Drive System Makes Parents Easier

As a way to add a bit of ease and convenience to your life being a parent, the stroller is a necessary item for baby safety and comfort.

Whether you’re walking around the block or packing up for your next family vacation, your stroller is going to be one of your most frequently used pieces of baby gear. Stroller Safeguard Your Baby With the invention of baby strollers, parents can carry their children with them anywhere. When parents travel with their baby, the stroller helps them get from one place to ...

More information

DC Gear Motor for Smart Indoor Lock

Rated Voltage: 5V No-load Speed: 36±15% Loading Speed: 31±15% Rated Loading Torque: 1500g.cm Rated Loading Current: 850mA MAX Transmission Ratio: 157.2:1 Noise: 60dB MAX

Feature: Low-noise. Greatly reduce the noise while using the lock through gear transmission. No more than 60dB. ZHAOWEI smart indoor lock gearbox solution enables large torque, compact size, high efficiency, low working temperature, and electromagnetic radiation. Multi-Application. The gear motor for a smart indoor motor can be used in various scenarios, like channel lo...

More information

Products associated

planetary gear-motor

ZWBMD004004-125
