The KIPP UNI lock zero-point clamping system facilitates the quick and precise clamping or referencing of fixtures and clamping components. This enables the zero-point clamping system to optimise work on machine-tools, machining centres and measuring equipment. Machine running times are increased through rapid changes, setup times are reduced. Thanks to the defined zero ...
The versatile range includes OEHT octagonal inserts for cutting depths 4 – 10 mm, alongside REHT (round) and XEHT (wiper) inserts. By utilising eight cutting edges – the highest number available for positive inserts – the new range provides an economical offer for customers, while the wiper insert option boosts feed rate capabilities and surface finish quality. P...
WORLDIA issue PCD milling tool for electronics industry, precision milling for shell of cellphone of aluminum-magnesium alloy material, pad, shell of notebook, and keyboard, etc. Features: 1. High precison, good stability and consistency; 2. Profile of any line tolerance 5um, chipping＜2um 3. Vacuum welding and high welding strength; 4. Adopt imported PCD tips 5. ...
The new Peter Wolters AC microLine® 535 can be equipped with or without water-cooled wheels. The Siemens servo-drives are a new design and will deliver 9,5kW (10-320 RPM) or 5,5kW (10-175 RPM). This leads to higher torque especially in lower RPM range. The pressure between the wheels will be controlled automatically and will be available from 500daN to 800daN, depending ...
The EWD Smart Damper damps vibrations and reduces chatter in deep-hole finish boring – thus achieving better surface finishes and improved metal removal rates. For precision machining of deep bores, it has previously been necessary to choose low cutting data in order to prevent vibrations, which massively increases processing time. The EWD Smart Damper overcomes this ...
All Hydromat Rotary Transfer machines are built as modular systems consisting of horizontal and vertical tool spindles rigidly mounted around a cast base with high-precision machining of all critical surfaces. This arrangement provides tremendous versatility and flexibility in a turnkey machining system. This current version of the EPIC R/T 45-12 machine features the new...
The rough pieces are placed into the loader, which feeds 1 piece on the working table. At this point the piece is clamped on one side and the loader goes back to the start position. One cutter, mounted on 2 slides driven by CNC, works out half of the profile. At the end of this operation the piece is clamped on the other side and the cutter works out the other half of th...
The TCN Series Heavy Duty CNC lathes, are available with turning diameter starting from 760 up to 2300mm and lengths up to 40,000 mm are highly reliable machines, specifically developed for heavy machining and with a high accuracy level. Those lathes are provided with a range of complete accessories. Our echoENG Product Specialists are available, upon request, to study s...
Tapping these materials using standard tools can often lead to tool breakage, because of their high level of toughness and tendency to fuse. The new high-end TC142 blind hole taps from Walter are precisely designed for machining ISO M materials. The TC142 comes in two variants: The WW60RB grade HSS-E-PM variant impresses with a long tool life and high cutting speeds t...
The company manufactures three lines of products: die & mould spotting presses (Blue Line); coil working plants (Green Line); conveyors and conveying systems (Yellow Line). Today MILLUTENSIL is one of the leader companies in this sector, with vice-presidents Beatrice and Veronica Just, who for several years now have been supporting their mother in the management of th...
HYDRO-GRIP high precision tool holders are your guarantee of secure clamping for milling, drilling and reaming tools. Their unique strength provides precision and rigid-tool stability to improve machining performance for the largest number of applications. With the extensive range of HYDRO-GRIP® high precision toolholders all application areas, from finishing to heavy ro...
- Powerful BBT 40 spindle with speeds up to 12,000 rpm - Rigid machine structure with extra deep center of gravity and small footprint (L version with larger work space) - Fanuc 0i MD control and Fanuc drives ensure a high degree of process safety - Short tool changing times for increased productivity and spindle up-time per shift Machine Design - Heavily ribbed...
The C 52 is setting standards, especially in challenging fields such as the aerospace industry (which uses primarily milling and turning in one clamping), tool and mould making (heavy, voluminous workpieces) and machine construction/contract manufacturing (high metal cutting capacity). High precision is emphasised in all machining tasks. The standard version of the C 52 ...
PSC coupling is expanding the already vast D’ANDREA program. It will appear at the EMO 2015. The new range includes both new monolithic tools with PSC coupling, both of which have new positions within the modular system (coupling, extensions and reductions). The “news” that D’ANDREA will be attending the EMO show in Milan over the next few days includes: modular cones, r...
- Rotation speed increased up to 4000rpm for faster carbide drilling - Even more rigid frame equipped with reinforced spindles, use of prestressed linear guides and ball screw - Use of new exclusive milling tools allowing the fast processing never ever seen before in this field - Development of software solution allowing new notching cycles by milling, simultaneous dr...
The VLC 100 GT integrates combination machining into EMAG’s well proven pick-up concept, where the main spindle is used to load and unload workpieces from the integrated conveyor belt or shuttle. The machining area is easy to equip with a variety of turning and grinding modules. This compact manufacturing system also includes integrated measuring. Machining processes ...
Top flexibility and autonomy with the modular machining cell •Automatic machining of different work-pieces or work-piece families in variable production lots •Automatic machine preparation (fixtures, robot grippers, cutting tools, pallets…) •Perfect organization of the chaotic production orders with Production Control System software (e.g. production lot changes or in...
The basic version includes 3 spindles to drill simultaneously the web and both flanges of H-beams, but also machine channels, angles, flat as well as right hollow sections, and a powerful operating system enabling part programing on 4 faces. Additional modules have been designed to increase the versatility of the machine: • Powerful spindle motors enabling fast carbi...
The new air turbine spindle enables existing machines to be cost-effectively upgraded and high-speed micro-machining to be done in a normal machining centre, without the need to purchase an expensive new high-speed machine. Operating at such high speeds helps to improve machining accuracy, enhance surface finish and significantly lengthen tool life, as well as reduci...
Available in MT, cyl. and VDI. Length tolerances and different centre bores are compensated through a travel stroke at fixed positions. Correspondingly light workpieces can be clamped very fine.
WORLDIA PCD Chipbreaker Inserts are suitable for machining aluminum alloys, copper alloys, magnesium alloys, all nonferrous materials, composites, reinforced plastic, and materials with abrasive binders. Eliminate bird nest chips when turning or boring, tailored to finishing or general machining operation. Descriptions: Adopted unique 3D chip breaking pocket design ...
Kitagawa's new GT Series rotary tables are a through hole series capable of withstanding high cutting loads. The series features 200mm to 320mm diameter tables and provides spindle rotations of up to 41.6 rev/min, for high speed indexing. Includes rigid body design to reduce deformation under heavy load. The pneumatically clamped GT Series incorporates pressure monito...
As a result, the F4042/F4042R becomes not only a roughing and finishing face milling cutter that enables the production of outstanding surfaces (Ra down to 0.2μ) , when fitted with the wiper indexable insert, it also fulfils all the prerequisites necessary for turn-milling. And let's not forget that at the end of the day, the user is spared the effort and expense of add...
HALL - 10; STAND - B32 DCK-CBH SERIES MICRO BORING TOOLS Features: ● Dial precision: 0.01 mm on diameter; ● Boring range: 20 - 929 mm; ● Internal-coolant through; ● With carbide inserts: TPGH0802; TCMT1102; TPGH1103; ● Three different insert holders for each boring head to increase boring range and also reduce the production cost; ● Balanced struc...
Since the introduction of the HBZ Trunnion series in 2012, the application diversity of the 5-axis HPC horizontal machining centres HBZ Trunnion has been continuously expanded regarding workpiece sizes (Ø max. 850, 1,300, 1,700 mm), materials (aluminum, steel, titanium) and sectors (aerospace, mould- and die, automotive, energy technology) and is operated successfully in...
JAKOB Antriebstechnik GmbH counters this problem with the motor-spindle safety system MS³. When peak forces occur, the MS³ detects the overload situation and decouples the machine tool from the spindle. The MS³ effectively prevents damage to critical spindle components without sacrificing machine tool rigidity or precision. The system’s kinematics includes an interlo...
PFL stands for a slide with conventional bellows, PCL means sheet metal cover (C for cover), and PKL stands for special protection against cooling media, as they are used in grinding machines in the form of water, grinding oil or emulsion. What all three slides have in common: More than ever before, they represent the Axis of Good. Precision in a new dimension The a...
With this drill, holes with a length/diameter ratio of up to 80xØ are possible in the range of Ø.25mm-1.50mm, in steps of .1mm for hole depths up to 20/40/60/80xØ. A centering/pilot hole of 2xØ is recommended to begin the process, with the deep-hole drill following with a peck-cycle until the hole is completed. The Sphinx micro deep-hole drill has a flute- and cutting...
The global company was founded in 2014 following the merger of round tools manufacturer Dormer Tools and cemented carbide tooling specialist Pramet Tools. It now aims to become the leading supplier of cutting tools and support services to the general engineering sector, with a comprehensive assortment of fit for purpose tools for drilling, milling, turning and thread...
Features: ● Twin-bit/Double-bit design makes two cutting option available: balanced cutting and stepped cutting; ● Balanced cutting for high-feed rate roughing operation; ● Stepped cutting for high cutting depth roughing operation; ● Boring range: 29-170 mm; ● Insert holder: AACC; ABCC; ● Inserts: CCMT0602; CCMT09T3; CCMT1204; ● Coolant-hole through;...
PFM - HSB are the right equipment for your beveling, facing and counter boring jobs. These jobs can be processed individually or simultaneously. They will perform repeatable high quality bevels with a I, V, J, X shape or compounded bevels. Perfectly suitable for manual or mechanised welding processes. The PROTEM PFM - HSB can achieve perfect weld preparations on a...
high-flow grinding and high-flow test capabilities to achieve finely tuned orifices in numerous design variations. To this end, Kennametal Precision Surface Solutions® is announcing PROGRESS, the next generation of flow tuning and flow measurement featuring a flow targeting accuracy to +/-1% aimed at orifices 100- 350 μm in parts less than 30 mm in diameter and flo...
Mechanic Travel in axis 300 x 210 y 100 z ball screw 12 X 5 mm 3 x stepper motor 0.9Nm Resolution 0.0125 mm rails and shoes prismatic Spindle 800W clockwise rotation rpm 10000/30000 collet 8mm Z adjustable in height Sensor tool Vacuum pip link Transparent cover in polycarbonate Fully enclosed 2 key for spindle ELECTRONIC COMMAND Programm...
The cross beam is fixed on machine body by angle iron frame, stability! The torch and THC are driven by drag chain instead of moving the whole beam, high precision! Streamlined machine body according with human body mechanics and having convenient operation! New THC get external PC board and cable, longer lifetime! Overall deisgn save you 50% space Duo ball linea...
Swiss precision for the fine art of exquisite watchmaking – this is the promise of the F-Decor 305 for best perlage quality. The compact machine offers highest variability, because the equipment can be exactly adapted to the needs of the customer: Three, four or five CNC axes, which always travel directly to the programmed position, one or two spindles which can be swive...
