BIG KAISER announced the Base Master Red, a high-precision compact touch sensor that rapidly determines workpiece offsets and tool lengths. Part of BIG KAISER’s popular Base Master family, this new sensor’s compact design makes it very fast and easy to use, while providing extremely accurate results. For rapid reference point detection, it is fitted with a bright red ...
The workpieces are clamped by means of a mandrel or similar device. Loading can be carried out manually, by the use of a handling system or by a robot (especially for series production). Processing is carried out by immersing the workpiece in a flowing stream of grinding or polishing medium. The media stream is generated by means of a rotating drum with a diameter of up ...
The new machine stands for cost efficiency “Made in Germany” by ALFRA. It is designed for a drilling capacity of 35 mm at a max. cutting depth of 50 mm and offers several features: Approved 1.100W motor with grease gearbox Self-adjusting guide rail Soft-touch-handles for better work Ergonomic switch keypad Solid 5m cable Inlaid ferrules for perfect magnet...
The specifications/applications of the New TAURUS® are : Nickel-based alloys Duplex and heat-resistant steels Titanium, titanium alloys Aluminum bronze Hardened and tempered steels (over 1000 N/mm²) Stainless and acid-resistant steels (austenitic) Stainless and acid-resistant steels (ferritic) Nitriding and high-speed steels Cast iron Tool steels Hardening s...
The continuously increasing demand of higher data rates requires high performance transmission systems able to handle Gigabit data rates. Our capacitive slip ring ROTOCAP facilitates uni- and bidirectional high-speed data transmission between rotating and stationary parts with up to Gigabit Ethernet rates. The data transmission is based on a non-contacting capacitive tra...
They specially mentioned that our MINIFLOOR can weld from one wall to the other. This makes re-welding the ends unnecessary. The MINIFLOOR sets new standards indeed. Those who already have a TRIAC, can convert it easily to a welding machine. According to product manager Lukas Odermatt it is worthwhile to upgrade. The result is top quality. Even very high quality requirem...
With the new VM 9 modular turning machine, EMAG has introduced a platform that covers a broad spectrum of applications thanks to the combined turning, milling and drilling technologies and intelligent machine design. The highly accessible machining area and workpiece spindle fitted at the bottom ensure short tooling times and maximum flexibility in the production of work...
Locking pins with folding latch are not only used for fast and easy fixing but also for permanent joining of movable parts and workpieces. The wide folding latch lets you secure the parts to be joined over a large cross section. It can also work under pressure in the axial direction. Indexing slots in the folding latch allow definite "Closed" and "Open" positions.
The specific technical features of these end mills are the large radii in the cutting area of the tools. Their geometry represents a part of a circle, a circle segment. The large radius simulates a ball-nose end mill with a cutting diameter of 12 to 3.000 mm. As a result, the axial depth of cut can be enlarged and simultaneous the surface quality will be improved. Due to...
WORLDIA PCD indexable face milling on end milling and shoulder milling of Non-ferrous metal, provide excellent surface milling of cylinder heads, motor blocks, gear boxes and pump cases. Description: Compare with the same pricing level products, this line of products has super higher flexibility, both roughing and finishing processing on one tool. Maximum reduce dow...
Cabe produces a complete line of slotting tools (dimensions from 4 mm - 25 mm). The tools are perfect for the Cabe slotting machines but can easily be used on every kind of slotting machine. The technical team studies the types of processes necessary for the client and provides the most suitable custom tools for the material or the cutting speed required. Each tool i...
The newest Cabe model promises the implementation of ground-breaking articulated machining. With great simplicity in its design, also supported by a constant cutting speed, the slotting machine ST4 CNC allows the execution of very complex figures, until now not impossible to realize using the traditional models. The software includes functionalities to realize decreasing...
This is not the case, however, if the tombstone itself is set on the MTS datum point. In this way, setting up takes place while the machine is in operation, and the tombstone with the machined parts is exchanged for one with new blanks in next to no time. The EROWA MTS system ensures precise positioning and also the best possible stability even with heavy chip-cutting...
The NMR chip breaker provides a reliable option for longitudinal and face turning with high stock removal in medium and roughing operations. This new geometry further enhances Pramet’s range of doubled-sided chip breakers for all turning stainless steel applications, which already includes NM for medium turning and NF for finishing to medium turning. NMR’s positiv...
ENCODER: the use of the LB Encoder allows precise, rapid machining. MACHINING SPEED UP TO 30,000 rpm: guarantees a high degree of finish on the operation. LIMITED THERMAL DILATATION OF THE SHAFT: the result of an HSD R&D project, this allows the motor power to be exploited to the best advantage. Contact us for a quotation!
Features : 1. High speed 2. High finish machining technology 3. High efficiency 4. Greatly save labor cost with the gantry loader, one worker at least controls six machines 5. Maintenance-free for 12 months Parameters: 1. 0-5500RPM for spindle, through-spindle hole diameter: 26(35) 2. X/Z-axis rapid traverse rate：20m/min 3. Max. turning diameter : 270, Max. Tu...
Equipped with synchronous motor and steel bearings lubricated for life, it requires little maintenance. The MMO-60 is available in 2 versions: water cooling, 2.4 Nm and 12,000 rpm or oil cooling, 2.2 Nm and 12,000 rpm. Following benefits are therefore guaranteed: • Increased production rates • Compact and lightweight optimized for easy integration • High performance i...
In April 2014, FAGOR ARRASATE delivereda 1000 tonne monoblock hydraulic press to FIBERPACHS S.A. to form composite materials at its facilities in Pacs del Penedes. The new features of the machine have been highly appreciated by the Customer, which has come to appreciate the complexity, quality and performance of the machine as well as the efforts undertaken by Fagor Arra...
This new generation of elbow mandrel assembly allows the positioning of a US-type machine on all types of elbows. Its concentric adjustment is due to the rules located around the system, this leads to a high quality weld-end preparation on all types of elbows and materials including stainless steel and high nickel alloys. The US 150 covers diameters ranging from 150 m...
from each other with a peak at 2 diameters. It can run on the same bar holes in any position with two different sizes. Drilling machine.
The latest version of the well regarded Lasertube family featuring fiber laser tilt head cutting of tubes up to dia. 240 mm (10”) and 40 kg/m (27 lb/ ft) with a fiber laser thanks to the new ‘Tube Cutter’ head designed by BLM GROUP. 3-RUNNER, E-SHAPE – two new models of tube benders 3-RUNNER and E-SHAPE make their debut in a manufacturing cell along with the proven SM...
Application : Nickel-based alloys Duplex and heat-resistant steels Titanium, titanium alloys Aluminum bronze Hardened and tempered steels (over 1000 N/mm²) Stainless and acid-resistant steels (austenitic)
The two new members of the M4000 milling cutter family are the M4575 T-slot milling cutter and the M4792 routing cutter. Together with the M4002 high-feed milling cutter, the M4132 shoulder milling cutter and the M4574 chamfer milling cutter, they make for a costeffective, flexible system that allows the user to tackle almost any milling task. In addition, the cutting...
The production of small high-tech parts in the watchmaking and jewellery industry and medical technology places special demands on the workpiece clamping technology. The wide product range of SPREITZER includes precision clamping solutions of different variants for the machining of small, sensitive and high-precision parts and components. SPREITZER now presents the s...
The rigidity of its design also enables it to machine valve seats down to depths of 500 mm (19.7"). Like the TU 400 and 600, it is equipped with automatic feed systems and can be fitted with an RTJ system. The FC 1150 option, a chain clamping system specially designed for these machines, is also available. Technical features: Facing Ø: 0 – 1100 mm (0‘‘ - 43.3‘‘) ...
Construction kit The basic rails of the CleverClamp workpiece tooling system are calibrated to fit the EROWA UPC and EROWA MTS production tooling systems. They can be used horizontally or vertically. The wide range of clamping elements can be positioned quickly on to the precisely toothed base rails. The basic rails provide a great deal of room for the flexible attachme...
A special attention was paid to the parts transfer and their support during machining thanks to feeding carriage system with grippers as well as ball table permanently supporting the plate. The standard 4-position automatic tool changer helps minimizing operator’s interventions. The closed portal machine frame ensures the highest rigidity during drilling operations. Ad...
Chicago , IL – On November 3rd, 2015 Madison Industries was pleased to announce that it has signed a definitive agreement with Kennametal Inc. (NYSE: KMT) to acquire seven businesses including Extrude Hone, Tricon, Landis, the Biel, Switzerland business of Kennametal Infrastructure and the Koblenz, Germany and Milan and Bellusco, Italy businesses of Kennametal Stellite....
The FiberStar Laser Cutter is available in variable sizes, the T24, T36 and T42, which are application specific depending on customer part size. The state-of-the-art, fully integrated fiber laser source provides excellent beam quality while producing many years of reliable performance. The cutting system offers a programmable 4-Axis (X/Y/Z and optional Rotary) CNC sy...
The new Z-Taps are available in two coating versions. In a first step they are designed for metric threads M4 to M10 according DIN 13 and M12 according DIN 376. The TIN-60 coated version is the specialist for steel materials and shows its strengths especially at steel materials with a tensile strength between 600 and 1,000 N/mm². A key role for the outstanding performanc...
The FCR and FCM Fullcut Mills are indexable insert endmills that deliver excellent cutting performance for demanding milling applications. They are available in many types and for every machine spindle, and are particularly well-suited to use with BIG-PLUS machine spindles with taper and face contact. To achieve the performance of solid endmills and reduce edge chip...
The PCD face milling cutter is used to process work pieces of various materials, including copper, aluminum, copper alloy, aluminum alloy and composite material. It can be used to process cast aluminum alloy engine case. PCD Milling Cutters provide excellent surface milling of cylinder heads, motor blocks, gear boxes and pump cases. Available with chipbreaker for opti...
Suitable for machining low carbon and soft stainless steels, the SD geometry supports both Pramet’s SCET and XPET ranges. The SD (soft drilling) chip breaker has been specifically designed to provide improved stability and productivity when drilling low strength soft and long-chipping material, where the balance of forces between the inserts becomes more difficult to ...
To cover the requirements of trochoidal machining, the end mills feature low-vibration characteristics such as variable spacing and variable helix angle or a new micro-geometry. The newly developed chip divider reduces the axial pull-out force of the tool and minimizes the risk of chip jams in pockets. The short chips can easily be removed with compressed air or emulsi...
The RC Deburring Tool’s pneumatically controlled, articulated design allows the cutting bit to follow the part profile and compensate for surface irregularities while maintaining a constant, settable force. This allows high feed rates with uniform quality in any orientation. The tool also requires no oil, allowing clean exhaust air to be vented directly into the work env...
The new, positive ISO indexable inserts have been developed by Walter on the basis of the high-performance cutting tool material, Tiger•tec® Silver. A PVD aluminium oxide coating protects the indexable inserts against wear, particularly at high machining temperatures. This makes them ideal for machining ISO M and ISO S materials. During the PVD process, deposition tak...
