Speed and Precision in Micro-Hybrid’s SMD Assembly

Surface-Mount Device (SMD) assembly defines today’s standard for miniaturization and functionality, but only when executed flawlessly.

In high-reliability sectors such as medical technology, industrial automation, and advanced sensor applications, product performance depends directly on manufacturing precision.

At Micro-Hybrid Electronic GmbH, our Electronics Assembly Hub is engineered to meet these exacting demands. We combine decades of German engineering expertise with state-of-the-art production technology to deliver tailor-made SMD solutions, from rapid functional prototypes to certified high-volume series production.

Precision and reliability for demanding applications worldwide are at the core of everything we do.

Flexibility in SMD Assembly
Our assembly lines are optimized for both extreme precision and high-speed throughput. Equipped with best-in-class systems from Yamaha, SMT, and MyData, we manage complex component mixes and tight schedules without compromising quality or repeatability.

Core Manufacturing Capabilities
• Component Handling Excellence: Fully automated placement systems achieve performance up to 90,000 components per hour. We handle the full spectrum of sizes - from the minuscule 01005 inch to highly complex BGA, QFP, CSP, and MELF packages.

• Double-Sided Complexity: Our systems process demanding double-sided boards with speed and accuracy, significantly reducing cycle times.
• Advanced Soldering Processes: We deliver the optimal thermal profile for every design with flexible soldering methods:

o Reflow Soldering (Full Convection) - reliable, high-quality processing.
o Vapor Phase Soldering - ideal for complex, temperature-sensitive components.
o Vacuum Soldering (SMT) - minimizes voids in BGA and power packages, ensuring superior mechanical and thermal performance.

• Material Versatility: We support multiple solder pastes, including lead-free alloys and adhesive mounting options tailored to your specific application.
Continuous process monitoring guarantees maximum reproducibility and cost-efficiency - ensuring every product meets its design specifications precisely.

Multi-Level Inspection
Micro-Hybrid integrates advanced, multi-level inspection at every production stage to eliminate assembly defects long before a circuit leaves our facility. As your partner for the development and production of innovative electronics solutions, we combine inspection excellence with complete data integrity.
Integrated Inspection Technology
• 2D and 3D AOI: Non-contact measurement of height, position, and solder volume in the micron range (µm) catches even the smallest irregularities.
• X-ray and CT Scans: Non-destructive imaging ensures internal bond quality in hidden joints such as BGAs and CSPs through volume and defect analysis.
• In-line Process Monitoring: Immediate optical and mechanical inspection after soldering verifies process stability and enables real-time correction.
Our advanced inspection chain ensures complete traceability, consistent quality, and confidence - even for the most densely packed, mission-critical assemblies.

Maximum Service Life
Long-term reliability in harsh environments is impossible without strict cleanliness. Residues and particles can lead to corrosion, leakage currents, and premature failure. That is why our automated multi-chamber cleaning system is designed for optimum surface purity across all assembly types, from high-power circuits to ultra-sensitive sensor modules.
Cleaning Protocol
• Customizable Programs: Variable cleaning cycles adapt time, temperature, and ultrasonic intensity to each PCB’s requirements.
• High-Sensitivity Washing: Fine-washing processes based on Neukum and ISO standards protect delicate and high-sensitivity PCBs.
• Verification and Partnership: Cleanliness is validated via Contaminometer analysis to measure particle load and surface resistance. Together with our long-term partner Zestron GmbH, we maintain industry-leading precision cleaning standards.

This controlled environment ensures stable electrical performance, robust corrosion prevention, and the long-term satisfaction of our customers.

Your Partner from Concept to Full-Scale Production
Micro-Hybrid accompanies your project through every stage: from early functional prototypes to optimized series production. Our modular assembly concept allows fast design adjustments, flexible material choices, and scalable volumes. This integrated approach shortens time-to-market and ensures your innovation moves efficiently from design to deployment.
We provide electronic solutions for a better world. Join start an inspiring journey, and combine technological excellence with sustainable, responsible manufacturing. We will be happy to advise you on your development project and the optimum substrate and packaging technologies.
