Float valves with vertical guide float

Valve solution for small tanks

The float valves, consisting of a PA 66 plastic body and an EPDM membrane, are mainly characterized by a high long term performance capability, high operating safety and a maximum operating pressure up to 10 bar (145 psi). Furthermore Cv-values of 25 l/min (DN 13) respectively 53 l/min (DN 17) are realized.

Characteristics

• Servo-controlled

• Designed for narrow and deep tanks

• Reduced dripping of the valve during closing due to a shorter closing time

• Medium temperature up to 60 °C (140 °F)

• Long term performance capability

• High operating safety by the use of high quality materials and 100% final testing of the products

• Two float shapes

Applications

• Tank filling

• Rain water utilisation

• Water treatment

More information

Details

Düsseldorf, Germany

A. u. K. Müller
