JINPAT has recently launched a rotary union series featuring low torque. Sealing surface or ring is made of special material to resist wear, rust and corrosion with no leakage. Two precise bearings are located inside the swivel joint, which allows a high-speed rotation with lasting smooth running and low friction coefficient. Such pneumatic rotary union can transmit comp...
Formerly to provide power , signal and gas \ liquid media transmission for the automation rotary equipment, using electrical slip ring connected with a pneumatic hydraulic rotary joint often makes it hard to install and space increased. To avoid this , the electrical pneumatic hydraulic hybrid rotary joint will be the best solution . AS high sealed requirements fo...
From manually operated to automated process valves, the new configurator for process valves from Festo makes selecting the optimum solution child's play. Simply select a few parameters and the configurator will immediately suggest appropriate combinations, making engineering in the process industry fast, reliable and easy. The configurator for process valve units sign...
NIV series gradient valves feature multiple 2-Way, Normally-Closed solenoids connected around a central body. This unique design provides significant reduction in internal volume with enhanced mixing capabilities. Each actuator operates independently, allowing for flow of various media to be mixed or for one media to be split into multiple streams. These multi-channel gr...
Spool dividers split the input flow proportionally into two output flows. Common output ratios are 50/50, 60/40 and 66.6/33.3, but any ratio is theoretically possible. The major components in a spool divider are a housing with an inlet port and two outlet ports; and an internal moveable spool. The spool features cross-drilled holes through the mid-point section, bisec...
This compact combination valve provides a complete solution to hydraulic motor control for mobile machinery and reduces both space and pressure drop in machinery used for mining, quarrying, construction and agricultural applications, without compromising performance. Visitors can see the valve in Stand/Hall B5-438J April 8-14. Webtec-CV120_2 hydraulic control valveThe...
Sun’s RVC valves offer fully adjustable, ventable and blockable relief functions for both mobile and industrial functions. They reduce complexity by combining the functionality of two valves into one body and one cavity, reducing materials and creating a more compact and efficient system. They also improve reliability because the main stage orifice is protected by ...
This requires the use of a valve that can operate efficiently under demanding conditions found in manufacturing sectors and is still able to perform adequately under changing conditions such as those seen in the oilfield. TPCI offers 3 valve configurations to meet this need: · A low suction pressure (2 POSIVA) configuration for use with less than adequate suction con...
Stop by the booth to see a fully functioning dewatering skid featuring the latest NETZSCH technology. Also to be highlighted is the line of NEMO® progressing cavity pumps, the NOTOS® Multi-Screw pump for mining, and the TORNADO® T2 rotary lobe pump. Stop by the booth to see safe, reliable and cost efficient NETZSCH mine dewatering pumps and pump skids ideal for mines ...
A multi-stage centrifugal pump contains two or more impellers in the same pump unit. Ring section pumps, which are a type of multistage centrifugal pump, have multiple stages arranged in tandem inside their casings. As the liquid passes through each stage, the pressure of the liquid increases. This is especially useful for certain applications, including boiler feed syst...
This eccentric plug rotary control valve can be used in both low and high pressure systems and can withstand clean, dirty, and corrosive liquids and gasses; and erosive and abrasive slurries. Featuring bi-directional flow capability, the K-Max can handle mediums that are normally flowed to open and flowed to close. The eccentric rotary plug action allows the plug t...
The flexible hoses, which are part of the Loc-Line range of modular hoses, can be attached to a central extractor system or industrial vacuum cleaners. Once attached, they can be positioned next to machinery to extract swarf, smoke, lubricant mist, steam, gases and other media which could be potentially damaging. Designed for maximum versatility, users can lengthen or...
Faulty O-rings can cause direct and indirect consequential costs through machine downtimes, recalls or environmental damage. In the presence of chemicals and additives as well as of elevated temperatures, these elastomer seals reach their limits of wear soon. Therefore, GEMÜ has developed an innovative sealing method without O-ring for its iComLine product range. Two con...
Ball valves can be used in a wide variety of applications in industrial processes, and in water supply and water treatment systems in particular. One of the most efficient filtration procedures in water treatment is reverse osmosis. During this procedure, the unclean water is pressed through a semi-permeable diaphragm at high pressure. This filters unwanted substances ou...
ARGO-HYTOS, Kraichtal, Germany, offers innovative powertrain valve systems that help OEMs and equipment users increase reliability, efficiency, performance and emissions compliance, as well as take advantage of modularity and flexibility in overall design. These include various screw-in and slip-in cartridge valves. For example, model PD2E direct-operated directional val...
Allergen Kits are ideal for companies who prefer to use the same conveyor system to process a variety of different types of products where cross-contamination is a concern. Processors who convey products that include common allergens such as milk, eggs, nuts, soy, wheat, fish, and shellfish will benefit by utilizing a DynaClean conveyor with an Allergen Kit. With an A...
The heavy duty cast iron frame design incorporates integrally cast support and ribbed mounting feet, which assure a solid, dependable pump installation and operation. One frame fits all pump sizes. The frame has a back pull-out design feature, which allows for easy inspection or maintenance without disturbing the piping to the pump. Wiping vanes reduce axial loading and ...
They easily attach to downspouts and are guaranteed to remove zinc and copper to allowable benchmark levels. The new product comes in two configurations: Zinc-B-Gone basic for attachment to downspouts and Zinc-B-Gone pro for monitored installations and large or combined downspouts with more complex water chemistry. For larger, more complex industrial applications, Zinc-B...
According to the scientists involved in this endeavor, the new technology has been optimized for the production of optical elements on an industrial scale. Optical fiber is widely used in communication today but it could someday end up obsolete like every other technology. With the miniaturization of devices in play, scientists and engineers have been trying to cre...
It is important for the xLC® stator adjustment system that the elastomer in the rigid metal sleeve of the stator is flexible, which was made possible with the development of the proven iFD stator® 2.0. The xLC® adjustment system uses this characteristic so that the elastomer is not vulcanized into the housing but rather fixed through axial pressing. To regulate the prelo...
The new ZR is available with or without integrated dryer. Ideal for applications in the food & beverage, electronics, automotive, textile and pharmaceutical industries, the water-cooled ZR 90-160 VSD+ is equipped with two high-efficiency permanent magnet motors, state-of-the-art compressor elements, a new cooler design and an improved monitoring system. The drive design...
“As customers transition from on/off control systems, Eaton’s ESVL9 valve provides a precise, compact solution for advanced proportional control,” said Matt DeBruine, global category lead, SiCV, Hydraulics, Eaton. “A part of Eaton’s broad portfolio of SiCVs, the latest offering extends our commitment to helping customers solve their toughest challenges.” The size 10 E...
This prevents accumulation of fluid that would adversely affect the service life of the pump and the oil. It is ideal for applications where water vapor is expected, such as low temperature sterilization and drying. The compact Pascal 2021 HW two-stage rotary vane pump resists aggressive chemicals such as hydrogen peroxide. Customized temperature management enables th...
The operator can pressurize and retract the tensioner directly from the pendant. The pump achieves high pressure without the need for an intensifier, which, the company says, allows for low-maintenance and less cost for the end user. The product is typically used in oil and gas, wind power, and power plant applications, and works well when used for critical joints in the...
The Houston-based manufacturer of oil and gas BOPs and well intervention systems says the design places a backup system in the body of the shear ram mechanism. A BOP is a specialized valve or mechanical device used to seal, control and monitor oil and gas wells to prevent blowouts. The shear ram is its closing element, normally used as a last resort to regain control ...
As the newest addition to Garlock's family of abrasion resistant expansion joint materials, ABRA-SHIELD will join ABRA-LINE and Natural Rubber to provide a variety of liners that cater to increased abrasion protection. ABRA-SHIELD will be an option for use with a number of expansion joint products that Garlock offers – including styles 204, 206, 7250, 8400 and 9394. The...
This high flow capacity volume booster comprises a 1:1 signal to output relay and an integral bypass valve that provides system stability while allowing normal positioner airflow and normal valve actuation with small input changes. The soft valve seat provides tight shutoff and eliminates leakage in steady state operation to reduce air consumption. The Type 6100 bo...
The compact rotary drive unit robolink RL-D-PT belongs to a modular system, which includes a variety of joints, motors and connecting parts. It enables precise manual adjustment of components and is used in applications where devices have to be set up infrequently, but with precision. It is pivoted and rotated using lubrication-free, lightweight plastic gears. The mounti...
Eaton’s new CLS 180 load-sensing sectional mobile valve is a post-compensated valve with a highly versatile design. This modularity is demonstrated through the availability of valve banks with up to 10 sections, a number of spool types and actuation options, mid-inlets, custom inlet manifolds and transition plates. With this flexibility, designers can build the valve to ...
Compared with other designs such as diaphragm, bladder and piston accumulators, the gas chamber in metal-bellows units is usually hermetically sealed and the metallic barrier between gas and fluid sides permits no permeation. This results in a design that has extraordinary media compatibility, an extremely wide operational temperature range, is maintenance free and maint...
Exhibiting in booth 741, Blackmer will be featuring STX Series pumps. STX Series transport pumps are ideal for loading and unloading corrosive and non-corrosive liquids – sulfonic acids, specialty chemicals, solvents, latex paints, liquid sugars and vegetable oils – that are not compatible for use with cast iron pumps. These pumps offer the best combined characteristics ...
Danfoss Turbocor® compressors are engineered and manufactured in Tallahassee and deployed around the world to help buildings reduce energy consumption and costs. New low-GWP refrigerant option R-513A is a low-GWP, non-flammable (A1) alternative refrigerant to R-134a that allows chiller manufacturers to meet future HFC regulations, such as the European Union’s F-gas...
The Ross Hydraulic Block & Bleed series features a manifold base mounted design available in three body sizes D03, D05, and D07, port sizes SAE-8, SAE-12, and 1-1/4 Code 61 Flange. These valve systems feature a relief valve on inlet, and position sensors for external monitoring. The HBB series valve system is enhanced with a tamper-resistant design that prevents unauthor...
Incorporating a sensor and electronics into the valve body enables a control loop within the system, so mechanical tolerances, friction and wear no longer lead to inaccuracies and failures in the drive movement. And for systems that require machine monitoring, sensor information can also be sent directly to the main controller. The PRM9-06 proportional directional v...
Flexible couplings for critical equipment must accommodate angular and axial movement due to thermal growth. In steam and gas turbine applications, machinery shafts, casings and piping expand as their temperature increases. When axial deflection is significant, spacers are purposely made short to stretch the coupling statically. As the machines grow toward each other...
The KPP05 Piston Pump may also be configured with alternate bore sizes when higher pressures or displacements are required. The product can also be equipped with a variety of accessories, including a range of mounting brackets and an adjustable home position switch. Potential applications for the Kinitics Automation KPP05 Piston Pump include acting as a master cylinder f...
